Mitre Saw

TC-MS 216

Item no.: 4300370 EAN: 4006825635683
  • High-quality carbide saw blade for a perfect cut
  • The work table is made of light and stable die-cast aluminum
  • Rotary table with snap-in positions at the most common angles
  • The saw head can be tilted up to 45° to the left for mitre cuts
  • Left and right with supports for long workpieces
  • Including a clamping device for fixing the workpiece
  • The spindle lock makes it easier to change the saw blade
  • Easy-to-read angle scales for precise bevel and mitre cuts.
  • Dust collector funnel behind the saw blade for better removal of sawdust
See more information
Article description

With the Einhell cross-cut mitre saw TC-MS 216, the ambitious DIYer is ideally equipped for demanding work at home, in a workshop or in a garage. With powerful 1,400 W, the saw blade (Ø216 outside x ø30 inside) works through the material to be processed. The work table is made of light and stable die-cast aluminum. The rotary table with the snap-in positions for the most common angles allows precise cuts to be made. The user will also find easy-to-read angle scales for oblique and mitre cuts. For the desired mitre cuts, the saw head can be tilted up to 45° to the left. The cutting width is up to 120 millimetres, depending on the angle of inclination. Practical supports for long workpieces are available on the left and right respectively. There is a useful clamping device to fix the workpieces. The high-quality and robust carbide saw blade provides a perfect cut. The spindle lock makes it easier for the user to change the saw blade. Behind the saw blade there is also a dust collector funnel for improved removal of sawdust.

Technical details

% power S625 %
Cutting depth 45° x 45°45 mm
Cutting depth 90° x 90°60 mm
Cutting width 45° x 45°80 mm
Cutting width 90° x 90°120 mm
Idle speed max.5000 min^-1
Number of saw blade 1 teeth48 pcs
Power S61600 W
Product weight8.27 Kg
Saw blade 1 diameter216 mm
Saw blade 1 typeCarbide tipped
Saw blade holder diameter30 mm
Suction connection diameter36 mm

Free of dust and chips

Behind the saw blade there is a rubber tab for improved sawdust removal. This protects against flying chips.


Practical angle setting

The high-quality die-cast aluminum turntable has locking positions for the most common angles for DIY work.


Need another saw blade?

The spindle lock and the easily accessible saw blade screw enable a simple, quick and above all safe saw blade change.


Flexible in any position

The cross-cut mitre saw has a tiltable saw head to the left (adjustable up to 45 degrees): Precise mitre cuts are therefore no problem.

Extensive sawing & cross-cut work? We have just the thing!

The Einhell cross-cut mitre saw TC-MS 216 can flexibly, quickly and easily cut a wide variety of materials such as wood or plastic. Extendable workpiece supports on the left and right provide support when working with large workpieces.
